Happy HCH - User-Defined Frames (6 ~ 20)

-D2 -133
13-A
FRAME CONFIRMATION
20_A M401
User-defined frames (6 ~ 20)
You need to prepare for the data which entered the shape of the frame and entry the entered
data.
You can entry the data up to 15 different size of custom frames.
You need to prepare custom frame size data for entry the size to your machine. 13-B
The embroidery area for each registered frame is set to the inside of the frame edge to allow for
pressure foot clearance. (Fig. 1)
Embroidery
area
Fig. 1
Embroidery
area
Round frame
Square frame
