-RA -58
10-3
READING
14_4 NB01
Pattern read settings
Settings related to pattern data reading:
Detailed explanation of machine setting
4 Stitch sweeper
This removes stitches that are extremely narrow when reading pattern data and writing to
machine memory. If thread breaks occur often at the same point in a pattern, this may be
because of narrow stitches.
If the thread still breaks in the same place you can use this function again but repeated
usage may distort the shape of the stitch.
1. Save the pattern to USB memory.
2. Conduct a stitch sweeping of the pattern and load it into the machine again.
End
7 Data format
This enables you to select a different format and read the pattern again if the machine did not
read it correctly the first time.
SETTING ITEM SETTING RANGE
(Difult is underlined)
1 Keep null (CHG.) Yes•No : This function lets the machine read zero stitches as they are before color
change when reading pattern data.
2 Skip null stitch Yes•
No : This lets you choose to ignore all null stitches when reading pattern
data.
3 Combine jump Yes•No : Allows you to combine multiple, consecutive jump stitches when
reading pattern data, if desired. It combines them into jump stitches of
the maximum 12.7mm and reads the pattern with the combined
jumps.
4
Stitch sweeper
Yes•No : This function eliminates extremely short stitch for stitch width when reading
pattern data.
5
Sweep length
0 ~ 0.4 ~ 0.8 : This setting controls the length of the stitches eliminated by the Stitch
(mm) sweeper. Stitches shorter than this setting will be eliminated.
6
DST name display
Yes•No : When patterns in Tajima format are read in, the display shows the file name.
7
Data format Auto ➞Automatic : Turn data format for reading patterns. Usually, set it to Automatic.
Happy➞
HAPPY,
Tajima
Brd ➞
Barudan
Zsk ➞Zsk
8
Design information
Yes•No : This function reads various function setting which are set in pattern data
together with pattern data (type TAP).
9 Trace type : Lets you select the type of trace data that is created as a pattern is read in.
➞ Maximum embroidery area of pattern
➞ Out line
10 Join design data Yes•
No : It is appeared that other pattern data is joined to the data previously read in
the machine.
You can make one pattern data by joining multiple pattern data read in the
machine.
11
Folder select
Yes•No : When reading pattern data, the list for selection of folders will be displayed.
To Next Page
