-D2 -83
14-3
PATTERN SETTINGS
12_3 NB01
Width adjustment
This setting adjusts stitch width (L) in a pattern
in a range of -1.0 ~ +1.0mm in increments of
0.1mm.
In case "Width" (Width adjustment) is set
and embroidery is made, there is a case
that error occurs at end point. In such a
case, please return setting figure of stitch
width to "0.0".
Setting example
1. When the machine is stopped, press
.
2. Select "SETTING".
3. Select
(Width adjustment).
4. Select the number.
Changing is cancelled.
Numbers are deleted.
5. Press .
The setting is fixed.
L
L + 0.4mm
0.4 mm
Default : 0 mm
Adjust
The pattern data may be shown.
Setting is returned to the default.
To return to Menu mode.
to return to Drive mode.
To Next Page
