MAIN PARTS
BOBBIN WINDING
7
5
6
1
4
2
3
1. Upper Thread guide
2. Thread stand pin
3. Thread stand felt
4. Thread guide
5. Winder thread guide
6. Spindle
7. Lever
CONTROL BOX
3
4
1. Display (L.C.D.)
2. LAN port
3. Thread cut button
4. Start/Stop button
5
3
6
1
16
7
5. USB port (Standard-A receptacle)
6. USB port (Standard-B receptacle)
7. Stylus
