ERRORS AND WHAT TO DO
24_2 O512
030 Slow mismatch Improper speed adjustment at low
speed. Speed does not decrease below
100rpm at low speed.
Re-initialize machine system and speed. 25-1
25-2
050 C point Main shaft is stopped in a position other
than "C" point
Follow the instructions below. 24-4
25-1
25-2
051 L sensor Timing detection board fault, or marred
photo-sensor. Malfunction of "Lowest
needle position" sensor [PH2] on
detection circuit board.
Improper adjustment of slit plate.
Check to see if photo sensor is clean or if
the slit plate contacts sensor.
Re-initialize machine system and speed.
25-1
25-2
052 C sensor Timing board detection fault, or marred
photo-sensor. Malfunction of "Color
change position" sensor [PH1] on timing
detection circuit board.
Improper adjustment of slit plate.
060 X limit Frame/pantograph has moved beyond
sewing area along X-axis.
Return frame within sewing area using
the frame movement keys on the control
boxl.
Check pattern size and center mark to
ensure that it is within size range of
selected hoop and also properly
centered.
061 Y limit Frame/pantograph has moved beyond
sewing area along Y-axis.
063 Drive Setup During embroidery, preparation for frame
movement did not complete within
predetermined time.
Malfunction of "Lowest needle position"
sensor on detection circuit board,
Improper adjustment. Re-initialize
machine speed. If this condition occurs
frequently, contact your Dealer.
25-2
066 Frame drive During embroidery, frame movement did
not complete within predetermined
moving time.
If this condition occurs frequently, contact
your Dealer.
090 Miss reception Error has occurred during data transfer
(via cable) between machine and PC.
Try reading pattern data again. 5-4
091 No send Machine has not received data for > 10
seconds during data transfer.
103 Data format Machine unable to determine format of
pattern data.
Verify format of pattern data and fix if
necessary.
10-3
104 Miss function Timing to read pattern data does not
conform.
Read pattern data again from the start. 5-4
105 Dual function Data has been detected in the pattern
that has ambiguous/dual function.
Read pattern data again from the start. 5-4
106 No function Interval between start read time and
time of reception of actual pattern data
is too great.
Check quality of design data.
108 Improper read While reading pattern data, error has
occurred in internal processing.
Read pattern data again from the start. 5-4
110 Memory full Memory has filled while reading in a
design.
Delete unnecessary patterns from
machine memory and try again.
5-B
111 Change over While reading pattern data, # of color
changes (color No.) has exceeded 250.
Divide pattern data such that number of
color changes of each segment is less
than 250.
112 Data error Pattern data of current design is
damaged.
Delete pattern and re-load. 5-B
114 Id over # of patterns in control panel memory
has exceeded the maximum of 250.
Delete unnecessary patterns from
machine memory and try again.
5-B
116 Not found Id Specified pattern does not exist. Check setting.
118 Trace data over Over 1024 stitches trace data were
created during reading of pattern data.
Set maximum stitch length to embroidery
area of pattern data within 2m
(lengthwise) x 2m (sideways).
120 Memory error Fault in retaining contents of pattern
memory.
If this occurs frequently, it is likely that
LCD-CE board is faulty.
Contact your Dealer.
