ERRORS AND WHAT TO DO
24_4 M201
C
1. Press .
2. Select "Auto".
The main shaft turns 2 to 3 times and returns to
a stop position (“C” point ) automatically.
The display returns to drive mode.
What to do when Stop position of main shaft is out of place (error E-050)
1. Press .
2. Select "Manual".
The error status is released and the display
shows “drive mode”.
3. Remove the cap over the small hole in the
rear of the machine. Using a 3 mm hexago-
nal driver, Please turn the main shaft and
adjust it to the “C” point.
CAUTION! <Main shaft turns>
When you cannot clear by the method above (Auto)
E-050 C point
OK
E-050 C point
OK
