-SJ -36
7. Press and keep until a fixing screw for
pressure foot appears at the position as
photo.
7-1b
CAP FRAME option
7-1b N401
Fixing screw for
pressure foot
CAUTION: To prevent accidents.
The needle will down.
Please keep your hands clear for your safety.
8. Using a 3 mm hexagonal driver, Please turn
the main shaft and adjust it to the "L" point.
10.Loosen a fixing screw for pressure foot.
Adjust distance between pressure foot and
a needle plate for cap to 1.2 mm.
Tight a fixing screw.
L
L
1.2mm
Fixing screw for
pressure foot
Needle plate
for cap
To Next Page
