86 ACO6800+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 8: ACO6800+ISCST Parameters, LEDs, and Alarms
Table 8-1. ACO6800+ISCST Cross-Functional Parameter Changes
Position Parameter Setting Unavailable Parameters
System
Operation Standard
• 1080i
• 1080p
• 720p
• EDH (Out 1_2 Settings)
• SD-SDI Mux 24 bits (audio)
Video > AUX Settings
AUX Output
Source
Frame Sync
• AUX OSD Enable
• AUX EDH
Audio > Processing >
SRC Bypass
SRC Bypass Mode Auto SRC (1-8) Bypass
Audio > Processing >
SRC Bypass
SRC Bypass Yes
Note Note: if the SRC Bypass
Mode is Auto and the audio
package is detected as Data,
ACO6800+ISCST will
automatically switch SRC *
Bypass to Yes.
•Gain Lock
• Gain All
• Gain (ch * -L/R)
•Invert All
• Invert (ch * -L/R)
Audio > Processing >
Delay
Delay Lock Yes Delay (1-16) (ch 1 - L–ch 8 -R)
No Delay All
Audio > Processing >
Gain
Gain Lock Yes Gain (1-16) (ch 1 - L–ch 8 -R)
No Gain All
Audio > Processing >
Phase Invert
Invert All On Invert (1-16) (ch 1 - L–ch 8 -R)
Audio > Output > MUX
Follow Input Yes SDI Grp (1–4) Mux En
