Chapter 1: Introduction
Applications
ACO6800+ modules allow broadcasters who must turn around large numbers of
signals (such as satellite direct-to home operations, cable head-ends, mobile
television operations, and IPTV operations) to provide two signal sources with
the ability to switch between the signals to play one on air.
Front Module
Figure 1-1 shows the position of the LEDs and module controls on the front of
the modules.
Figure 1-1. Typical Module
Table 1-2 on page 5 briefly describes the LEDs, switches, and jumpers.
Module status LED
Mode select
rotary switch
Navigation
toggle switch
Monitoring
LEDs
Control
LEDs
Extractor
handle
