ACO6800+ Installation and Operation Manual 41
Copyright © 2009, Harris Corporation
Chapter 4: ACO6800+ISD Parameters, LEDs, and Alarms
LEDs and Alarms
The ACO6800+ISD modules have LEDs that serve as a quick monitoring
reference, and one module status LED. Figure 4-1 shows the location of the
LEDs on a typical ACO6800+ISD module. Table 4-3 and Table 4-4 describe
each LED in more detail.
Figure 4-1. Location of ACO6800+ISD LEDs
Monitoring LEDs
Module status LED
