Chapter 4: ACO6800+ISD Parameters, LEDs, and Alarms
ACO6800+ISD Subdevice Parameters
The parameters in SDI mode and in ASI mode cannot be shown at the same
time.
Table 4-2. ACO6800+ISD Subdevice Parameters
Group Parameter Name
Bank, Switch
Function Options
Parameters available in SDI Mode
Status
Video Present [RO] Indicates that video is present
•On
•Off
Video Standard [RO] Lists the incoming video standard <string>
Audio Grp (1-4) Present Displays the presence of the
specified audio group package
•On
•Off
SQM Settings
Set Expected Video Standard
A1
A2
2, 1
3, 1
Selects the expected format
Note When the format deviates
from this format, one of the SDI
Video Standard Mismatch alarms
triggers.
• 525
•625
• 1080i
• 1080p
•720p
• 1080psf
Luma Low Threshold
A1
A2
2, 2
3, 2
Sets the threshold below which the
SDI Luma Low alarm is triggered
-6.8% to 15% (7.5%)
Luma Peak Threshold
A1
A2
2, 3
3, 3
Sets the threshold at which
excessive luminance triggers the
SDI Luma Peak alarm
90% to 108% (102%)
Chroma Low Threshold
A1
A2
2, 4
3, 4
Sets the threshold below which the
SDI Chroma Low alarm is
triggered
0% to 15% (0%)
Chroma Peak Threshold
A1
A2
2, 5
3, 5
Sets the threshold at or above
which an excessive chrominance
level triggers the SDI Chroma
Peak alarm
90% to 108% (102%)
