Harris ACO6800+ISD - ACO6800+DSD Subdevice Parameters

ACO6800+ Installation and Operation Manual 51
Copyright © 2009, Harris Corporation
Chapter 5: ACO6800+DSD Parameters, LEDs, and Alarms
ACO6800+DSD Subdevice Parameters
The parameters in SDI mode and in ASI mode cannot be shown at the same
time.
Group B GPI Output_3
[RO]
Displays whether or not the relay bypass
has been activated
•N/A
• Signal Bypass
ACO Group B > MISC Settings
Out B EDH Control 4, 5 Inserts or clears the EDH when the input
online is SD
Note This parameter is not available in
ASI mode, and is grayed out when the
selected input is HD.
• Insert
• Clear
Table 5-1. ACO6800+DSD Parameters (Continued)
Group Parameter Name
Bank, Switch
Function Options
Table 5-2. ACO6800+DSD Subdevice Parameters
Group Parameter Name
Bank, Switch
Function Options
Parameters available in SDI Mode
Status
Video Present [RO] Indicates that video is present
•On
•Off
Video Standard [RO] Lists the incoming video standard <string>
SQM Settings
Set Expected Video
Standard
A1
A2
B1
B2
2, 1
3, 1
5, 1
6, 1
Selects the expected format
Note When the format deviates from
this format, one of the SDI Video
Standard Mismatch alarms triggers.
• 525
• 625
• 1080i
• 1080p
• 720p
• 1080psf
Parameters available in ASI Mode
Status
ASI Error [RO] Displays where or not there is an ASI
error (including ASI loss)
•On
•Off
