Chapter 4: ACO6800+ISD Parameters, LEDs, and Alarms
ACO6800+ISD Parameters
Table 4-1. ACO6800+ISD Parameters
Group Parameter Name
Bank, Switch
Function Options
General
Serial Number [RO] Displays the serial number of the
module
<string>
License Key Provides a location for entering
license key numbers
<string>
Enabled Options [RO] Displays the current license option <string>
Factory Recall 0, F Sets the module back to factory
default settings
Note There are two independent sets
of default values for SDI mode and ASI
mode. Factory Recall in SDI mode
does not affect the parameters in ASI
mode, and vice versa.
•On
• Off
Soft Reboot 0, E Activates a soft reboot of the module
•On
• Off
Operation Mode 0, 1 Sets the ACO work mode to SDI or
ASI
Note Factory recall does not change
this parameter. It has no default value.
•SDI
•ASI
Thumbnail Source 0, 2 Selects the thumbnail source
Note This parameter is not available
in ASI mode.
• Input A1
• Input A2
• Output GrpA
Submodule Type [RO] Displays whether or not there is a
submodule included on the module
•None
•For ISCS
Backmodule Type [RO} Displays which back module is
connected to the front module
• For DS/IDS
•For ISCS
ACO Group A > Switch Settings
Group A Output Source
[RO]
Displays the current output source
• Input A1
• Input A2
Group A Switch High
Priority
1, A Sets the high priority for switching
• GPI Input
•Manual
•Alarms
Group A Switch
Medium Priority
1, B Sets the medium priority for
switching
• GPI Input
• Manual
•Alarms
