ACO6800+ Installation and Operation Manual 53
Copyright © 2009, Harris Corporation
Chapter 5: ACO6800+DSD Parameters, LEDs, and Alarms
Monitoring LEDs
Table 5-3. ACO6800+DSD Monitoring LEDs Indicators
LED Name Description Color Indication
1 Out A LED 1 The current selected input is 1A for group A. Green
2 Out A LED 2 The current selected input is 2A for group A. Green
3 IN 1A Present Input 1A signal is present. Green
4 IN 1A Alarm Input 1A is in an alarm state. Amber
5 IN 2A Present Input 2A signal is present. Green
6 IN 2A Alarm Input 2A is in an alarm state. Amber
7 Out B LED 1 The current selected input is 1B for group B. Green
8 Out B LED 2 The current selected input is 2B for group B. Green
9 IN 1B Present Input 1B signal is present. Green
10 IN 1B Alarm Input 1B is in an alarm state. Amber
11 IN 2B Present Input 2B signal is present. Green
12 IN 2B Alarm Input 2B is in an alarm state. Amber
