Harris ACO6800+ISD - ACO6800+IDSD Subdevice Parameters

ACO6800+ Installation and Operation Manual 61
Copyright © 2009, Harris Corporation
Chapter 6: ACO6800+IDSD Parameters, LEDs, and Alarms
ACO6800+IDSD Subdevice Parameters
The parameters in SDI mode and in ASI mode can not be shown at the same
time.
Group B GPI Output_3
[RO]
Displays whether or not the relay bypass
has been activated
•N/A
• Signal Bypass
ACO Group B > MISC Settings
Out B EDH Control 4, 5 Inserts or clears the EDH when the input
online is SD
Note This parameter is not available in
ASI mode, and is grayed out when the
selected input is HD.
• Insert
• Clear
Table 6-1. ACO6800+IDSD Parameters (Continued)
Group Parameter Name
Bank, Switch
Function Options
Table 6-2. ACO6800+IDSD Subdevice Parameters
Group Parameter Name
Bank, Switch
Function Options
Parameters available in SDI Mode
Status
Video Present [RO] Indicates that video is present
•On
•Off
Video Standard [RO] Lists the incoming video standard
Audio Grp (1-4) Present Displays the presence of the specified
audio group package
•On
•Off
SQM Settings
Set Expected Video Standard
A1
A2
B1
B2
2, 1
3, 1
5, 1
6, 1
Selects the expected format
Note When the format deviates from this
format, one of the SDI Video Standard
Mismatch alarms triggers.
• 525
•625
• 1080i
• 1080p
•720p
• 1080psf
Luma Low Threshold
A1
A2
B1
B2
2, 2
3, 2
5, 2
6, 2
Sets the threshold below which the SDI
Luma Low alarm is triggered
-6.8% to 15%
(7.5%)
