ACO6800+ Installation and Operation Manual 17
Copyright © 2009, Harris Corporation
Chapter 3: Configuration and Operation
Changing Parameter Settings
You can control the ACO6800+ modules at the card edge, or by using
CCS-enabled hardware and software applications.
ACO6800+ASID does not use card-edge controls.
CCS Navigator
Before using CCS Navigator to change your module’s parameter settings, you
must discover the module. Discovery is the process by which your software
finds, and then connects to your module.
Discovering a Module
To discover your module, your CCS Navigator software must be in Build mode.
Follow these steps:
1. If the Discovery pane is not open, select Tools > Discovery in the main
menu.
A Discovery pane opens, most likely in the bottom left corner of the screen.
2. Click Options, and then click Add.
3. Enter the IP address of the frame that contains your module, the frame that
contains your ICE6800
+ module, or the frame that contains a 6800+ETH
module that provides access to your module.
4. Click OK, and then OK again to close the Discovery Options dialog box.
5. Click Start.
This causes Navigator to run a discovery.
6. When your discovery is complete, Discovery Completed is displayed in
the Discovery pane. To continue, click Save, to save the contents of your
discovery to the Discovery folder of the Navigation pane.
