Chapter 6: ACO6800+IDSD Parameters, LEDs, and Alarms
ACO6800+IDSD Parameters
Table 6-1. ACO6800+IDSD Parameters
Group Parameter Name
Bank, Switch
Function Options
General
Serial Number [RO] Displays the serial number of the module <string>
License Key Provides a location for entering license
key numbers
<string>
Enabled Options [RO] Displays the current license option <string>
Factory Recall 0, F Sets your module back to factory default
settings
Note There are two independent sets of
default values for SDI mode and ASI mode.
Factory Recall in SDI mode does not affect
the parameters in ASI mode, and vice
versa.
•On
• Off
Soft Reboot 0, E Activates a soft reboot of the module
•On
• Off
Operation Mode 0, 1 Sets the ACO work mode to SDI or ASI
Note Factory recall does not change this
parameter. It has no default value.
•SDI
•ASI
Thumbnail Source 0, 2 Selects the thumbnail source
Note This parameter is not available in
ASI mode.
• Input A1
• Input A2
• Input B1
• Input B2
• Output GrpA
• Output GrpB
Submodule Type [RO] Displays whether or not there is a
submodule included on the module
• None
•For ISCS
Backmodule Type [RO} Displays which back module is
connected to the front module
•For DS/IDS
•For ISCS
ACO Group A > Switch Settings
Group A Output Source
[RO]
Displays the current output source
• Input A1
• Input A2
Group A Switch High
Priority
1, A Sets the high priority for switching
• GPI Input
• Manual
•Alarms
Group A Switch
Medium Priority
1, B Sets the medium priority for switching
•GPI Input
• Manual
•Alarms
