Chapter 5: ACO6800+DSD Parameters, LEDs, and Alarms
LEDs and Alarms
The ACO6800+DSD modules have LEDs that serve as a quick monitoring
reference, and one module status LED. Figure 5-1 shows the location of the
LEDs on a typical ACO6800+DSD module. Table 5-3 and Table 5-4 describe
each LED in more detail.
Figure 5-1. Location of ACO6800+DSD LEDs
Monitoring LEDs
Module status LED
