Chapter 9: Specifications
Inputs
HD/SD-SDI Video
ASI Transport Stream
Table 9-1. HD/SD-SDI Video Input Specifications
Item HD-SDI Specification SD-SDI Specification
Number of inputs
4 for ACO6800+ DSD and ACO6800+IDSD, 2 for ACO6800+ISCST and ACO6800+ISD
Standards
ACO6800+ISD, ACO6800+DSD, and
ACO6800+IDSD
SMPTE274M: 1080i/60,1080i/59.94,
1080i/50, 1080p/30, 1080p/29.97, 1080p/25,
1080p/24, 1080p/23.98
SMPTE296M: 720p/60, 720p/59.94, 720p/50
SMPTE RP-211-2000
1080psf/24, 1080psf/23.98)
ACO6800+ISCST
SMPTE274M: 1080i/59.94, 1080i/50,
1080p/25, 1080p/23.98
SMPTE296M: 720p/59.94, 720p/50
SMPTE 259M-C 270 Mbps, 525/625
component video
Connector
BNC per IEC 169-8 BNC per IEC 169-8
Impedance
75Ω 75Ω
Return loss
>15 dB (typical) from 5 MHz to 1485 MHz >15 dB (typical) from 5 MHz to 270 MHz
Equalization
Adaptive cable equalization for up to 393 ft (120 m),
typical, of Belden 1694A coaxial cable
Up to 918 ft (280 m) for Belden 1694A
Table 9-2. ASI Transport Stream Input Specifications
Item ASI Specification
Number of inputs 2 for ACO6800+ASID
Standards
DVB-ASI, 270 MB/sec
Connector
BNC per IEC 169-8
Impedance
75Ω
Return loss
>15 dB (typical) from 5 MHz to 270 MHz
Signal level 800 mV ± 10%
D.C. offset
0.0 V ± 0.5 V
Rise and fall time 400 ps to 1500 ps (20% to 80%)
Overshoot <10% of amplitude
Jitter < 0.2 UI (pk-to-pk)
