Chapter 6: ACO6800+IDSD Parameters, LEDs, and Alarms
LEDs and Alarms
The ACO6800+IDSD modules have LEDs that serve as a quick monitoring
reference, and one module status LED. Figure 6-1 shows the location of the
LEDs on a typical ACO6800+IDSD module. Table 6-3 and Table 6-4 describe
each LED in more detail.
Figure 6-1. Location of ACO6800+IDSD LEDs
Monitoring LEDs
Module status LED
