42 ACO6800+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 4: ACO6800+ISD Parameters, LEDs, and Alarms
Monitoring LEDs
Table 4-3. ACO6800+ISD Monitoring LEDs Indicators
LED Name Description Color Indication
1 Out A LED 1 The current selected input is 1A for group A. Green
2 Out A LED 2 The current selected input is 2A for group A. Green
3 IN 1A Present Input 1A signal is present. Green
4 IN 1A Alarm Input 1A is in an alarm state. Amber
5 IN 2A Present Input 2A signal is present. Green
6 IN 2A Alarm Input 2A is in an alarm state. Amber
7 Out B LED 1
Not used
8 Out B LED 2
9 IN 1B Present
10 IN 1B Alarm
11 IN 2B Present
12 IN 2B Alarm
