Chapter 8: ACO6800+ISCST Parameters, LEDs, and Alarms
ACO6800+ISCST Parameters for SDI
Table 8-2. ACO6800+ISCST SDI Parameters
Group Parameter Name
Bank, Switch
Function Options
General
Serial Number [RO] Displays the serial number of the
module
<string>
License Key [RO] Displays the license code of the
module
<string>
Enabled Options [RO] Displays the current license option <string>
Factory Recall 0, F Sets your module back to factory
default settings
Note There are two independent sets
of default values for SDI mode and ASI
mode. Factory Recall in SDI mode does
not affect the parameters in ASI mode,
and vice versa.
•On
• Off
Soft Reboot 0, E Activates a soft reboot of the module
•On
• Off
Operation Mode 0, 1 Sets the ACO work mode to SDI or
ASI
Note Factory recall does not change
this parameter. It has no default value.
•SDI
•ASI
SubmoduleType [RO] Shows whether there is a submodule
included on the module
• None
•For ISCS
Back Module Type Displays the type of back module
connected to the front module
•For DS/IDS
•For ISCS
System
Genlock Source 0, 2 Selects the genlock source
•Frame
• External
Sync Mode Set 0, 3 Sets the sync mode for the system
• Freerun
• Genlock
Sync Mode Feedback
[RO]
Displays the current sync mode
Note If genlock is not available, system
operates in freerun mode.
• Freerun
•Genlock
Operation Frame Rate 0, 4 Sets the operation frame rate for
system
Note The Auto option is only available
when sync mode is genlock.
• 25Hz or 50Hz
• 29.97Hz or 59.94Hz
• Auto
