88 ACO6800+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 8: ACO6800+ISCST Parameters, LEDs, and Alarms
Operation Standard 0, 5 Sets the operation standard for the
system
Note The available options depend on
the system’s operation frame rate.
<operation frame rate>
(default: 525/625)
Genlock Present [RO] Displays whether the genlock is
present or not
•On
•Off
Genlock Lock Status
[RO]
Displays whether the genlock is
locked or not
•On
•Off
Genlock Standard
Feedback [RO]
Displays the genlock standard <string>
System > Switch Settings
Output Source [RO] Displays which output source is active
Input 1
Input 2
Still Image
Switch High Priority 1, A Sets the high priority for switching
GPI Input
•Manual
•Alarms
Switch Medium Priority 1, B Sets the medium priority for switching
GPI Input
Manual
•Alarms
Switch Low Priority 1, C Sets the low priority for switching
GPI Input
•Manual
•Alarms
Alarms Switch Level 1, D Sets the level for alarm auto switch 1 to 10 (6)
Manual Switch 1, E Sets the what the output source will be
when a channel is switched manually
Disable
•IN_1
•IN_2
Relay Bypass 1, 1 Determines whether or not the relay
bypass is activated
•On
Off
Relay Status [RO] Displays whether or not the bypass
relay has been activated
•On
•Off
System > General Purpose Interface
GPI Input Trigger Level 1, 2 Sets the level at which an alarm is
triggered for the GPI Input of group A
Active Low
Active High
GPI Output Trigger
Level
1, 3 Sets the level at which an alarm is
triggered for the GPI Output group A
Active Low
Active High
Table 8-2. ACO6800+ISCST SDI Parameters (Continued)
Group Parameter Name
Bank,
Switch
Function Options
