ACO6800+ Installation and Operation Manual 69
Copyright © 2009, Harris Corporation
Chapter 6: ACO6800+IDSD Parameters, LEDs, and Alarms
SDI Embedded
Ch(01–16) Low Audio
Detects that the peak audio sample has stayed
below the level set in the Low Audio Threshold
parameter
1 30.0 2.0
SDI Embedded
Ch(01–16) Missing
Reports if the SDI embedded audio channel is
missing
1 1.0 2.0
SDI Embedded Audio
Group (1–4) Missing
Reports that the audio in the specified group is not
present
1 1.0 2.0
ASI Mode
ASI Error
Reports an ASI error (including ASI loss) in
streaming
1 1.0 2.0
Table 6-7. ACO6800+IDSD Subdevice Alarms (Continued)
Alarm Name Alarm Description
Alarm Option Default
Settings
Alarm
priority
Trigger
(s)
Clear
(s)
