Chapter 6: ACO6800+IDSD Parameters, LEDs, and Alarms
Main Device Alarms
These alarms are available in both ASI and SDI modes.
Subdevice Alarms
Table 6-7 describes the alarms for each of the subdevices on the
ACO6800+IDSD module. You can only identify specific alarms using a
software control application. Depending on which module you are using, some
of the subdevice alarms may not be available.
Trigger (s) This option determines how long an alarm condition must exist (in
seconds) before the alarm is triggered. If the alarm level is reached
for less time than the Trigger duration, then the alarm will not
trigger. Choose any duration from 0 to 7200 (or 2 hours). If this
option is set to 0 and the alarm condition exists for any period of
time, the alarm will trigger.
Clear (s) Determines the amount of time the alarm condition must be in
abate in order for the alarm to be turned off.
Choose any duration from 0 to 7200 seconds (or 2 hours). If this
option is set to 0 and the alarm condition ceases for any period of
time, the alarm will clear.
Ack When an alarm is active, click here to allow other users on the
network to see that you have acknowledged the alarm.
Table 6-5. Alarm Options
Alarm Option Effect
Table 6-6. Device Alarms For ACO6800+IDSD Modules
Alarm Name Priority Trigger (s) Clear (s)
Grp A Relay Bypass On 1 1.0 s 2.0 s
Grp B Relay Bypass On 1 1.0 s 2.0 s
Table 6-7. ACO6800+IDSD Subdevice Alarms
Alarm Name Alarm Description
Alarm Option Default
Settings
Alarm
priority
Trigger
(s)
Clear
(s)
SDI Mode
SDI Video Standard
Mismatch
The standard video input does not match the
expected standard
1 2.0 2.0
SDI EDH Error Reports recurring EDH errors in the standard
definition video signal
1 2.0 2.0
SDI CRC Error Reports recurring CRC errors in the high definition
video signal
1 2.0 2.0
SDI Loss of Video Reports that active HD or SD video has not been
present
6 2.0 2.0
