Chapter 8: ACO6800+ISCST Parameters, LEDs, and Alarms
LEDs and Alarms
The ACO6800+ISCST modules have LEDs that serve as a quick monitoring
reference, and one module status LED. Figure 8-1 shows the location of the
LEDs on a typical ACO6800+ISCST module. Table 8-5 and Table 8-6 describe
each LED in more detail.
Figure 8-1. Location of ACO6800+ISCST LEDs
Monitoring LEDs
Module status LED
