98 ACO6800+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 8: ACO6800+ISCST Parameters, LEDs, and Alarms
Audio Average Level Reporting
IN 1
IN 2
2, A
3, A
Displays the SDI Embedded Channel
Average Level value
• Enable
• Disable
Audio Average Level Restart
IN 1
IN 2
2, B
3, B
Restarts the calculation of the average
audio level
•On
•Off
SQM
SDI Emb.Ch1–16 Average Level
(dBFS)
Displays the embedded audio average
level for the channel
-99 dBFS to 0
dBFS
Parameters available in ASI Mode
Status
ASI Error [RO] Displays where or not there is an ASI
error (including ASI loss)
•On
•Off
Table 8-4. ACO6800+ISCST Subdevice Parameters (Continued)
Group Parameter Name
Bank, Switch
Function Options
