ACO6800+ Installation and Operation Manual 97
Copyright © 2009, Harris Corporation
Chapter 8: ACO6800+ISCST Parameters, LEDs, and Alarms
Table 8-4. ACO6800+ISCST Subdevice Parameters
Group Parameter Name
Bank, Switch
Function Options
Parameters available in SDI Mode
Status
Video Present [RO] Indicates that video is present
•On
•Off
Video Standard [RO] Lists the incoming video standard <string>
Match With Operation Standard Displays whether the input signal
standard is the same as the operation
standard
•On
•Off
Audio Group (1-4) Present Displays the presence of audio group
package
•On
•Off
SQM Settings
Luma Low Threshold
IN 1
IN 2
2, 2
3, 2
Sets the threshold below which the SDI
Luma Low alarm is triggered
-6.8% to 15%
(7.5%)
Luma Peak Threshold
IN 1
IN 2
2, 3
3, 3
Sets the threshold at which excessive
luminance triggers the SDI Luma Peak
alarm
90% to 108%
(102%)
Chroma Low Threshold
IN 1
IN 2
2, 4
3, 4
Sets the threshold below which the SDI
Chroma Low alarm is triggered
0% to 15%
(0%)
Chroma Peak Threshold
IN 1
IN 2
2, 5
3, 5
Sets the threshold at or above which
excessive chrominance level triggers the
SDI Chroma Peak alarm
90% to 108%
(102%)
Video Black Threshold
IN 1
IN 2
2, 6
3, 6
Sets the threshold below which the SDI
Video Black alarm is triggered
0% to 10%
(5.5%)
Peak Audio Threshold (dBFS)
IN 1
IN 2
2, 7
3, 7
Sets the threshold above which SDI
Embedded Ch01 peak to SDI Embedded
Ch02 peak alarms are triggered
-20 dBFS to 0
dBFS
(-2 dBFS)
Low Audio Threshold (dBFS)
IN 1
IN 2
2, 8
3, 8
Sets the threshold below which SDI
Embedded Ch01 Low Audio to SDI
Embedded Ch16 Low Audio alarms are
triggered
-80 dBFS to -30
dBFS
(-60 dBFS)
Loss of Sound Threshold (dBFS)
IN 1
IN 2
2, 9
3, 9
Sets the threshold below which SDI
Embedded Ch01 Loss of Sound to SDI
Embedded Ch16 Loss of Sound alarms
are triggered
-100 dBFS to
-60 dBFS
(-90 dBFS)
