Chapter 7: ACO6800+ASID Parameters, LEDs, and Alarms
Monitoring LEDs
Module Status LEDs
The ACO6800+ASID module does not have any card-edge alarms. Instead, the
module status LED on the corner of the module lights up if an error is detected.
See Figure 7-1 on page 78 for the location of the LED, and Table 7-3 for a
description of the LED colors.
If the LED is flashing red, contact your Customer Service representative.
Alarms
If a major or minor alarm is triggered within your modules, the Status LED will
light red.
Table 7-2. ACO6800+ASID Monitoring LEDs Indicators
LED Name Description Color Indication
1 Out A LED 1 The current selected input is 1A for group A. Green
2 Out A LED 2 The current selected input is 2A for group A. Green
3 IN 1A Present Input 1A signal is present. Green
4 IN 1A Alarm Input 1A is in an alarm state. Amber
5 IN 2A Present Input 2A signal is present. Green
6 IN 2A Alarm Input 2A is in an alarm state. Amber
7 Out B LED 1
Not Used
8 Out B LED 2
9 IN 1B Present
10 IN 1B Alarm
11 IN 2B Present
12 IN 2B Alarm
Table 7-3. Module Status LED Descriptions
LED Color
Sequence
Meaning
Off There is no power to the module; the module is not operational.
Green There is power to the module; the module is operating properly.
Red There is an alarm condition.
Flashing Red The module has detected a hardware/firmware fault.
Yellow The module is undergoing configuration.
