Chapter 2: Installation
Maximum 6800+ Frame Power Ratings
The power consumption for the ACO6800+ISD, ACO6800+DSD,
ACO6800+ASID, and ACO6800+IDSD 2-slot modules is less than 12 W. The
power consumption for the three-slot ACO6800+ISCST module is less than 13
W. Table 2-2 shows the maximum allowable power ratings for 6800+ frames.
Note the given maximums before installing any 6800+ modules in your frame.
Due to high levels of heat dissipation, the modules should not be installed in
frames without fans. The modules cannot be installed in FR6802+DM and
6800/7000 series frames.
Note
Note
To maintain proper temperatures, ensure that the front panel is closed at all
times, and that the fan module is fully operational.
Table 2-2. Maximum Power Ratings for 6800+ Frames
6800+ Frame
Type
Max. Frame
Power
Dissipation
Max Power
Dissipation
for Two
Slots
Max Power
Dissipation
for Three
Slots
Max. Number of
ACO6800
+ISD/
ACO6800+DSD/
ACO6800+ASID/
ACO6800+IDSD
Modules
*
Max. Number of
ACO6800 +ISCST
Modules
†
FR6802+QXF
(frame with AC or
DC power supply)
120 W 12 W 18 W 10 6
FR6802+XF
(frame with AC
power supply)
120 W 12 W 18 W 10 6
FR6802+XF-48
(frame with DC
power supply)
105 W 10.5 W 15.25 W 9 6
FR6822+
(frame with AC or
DC power supply)
120 W 12 W 18 W 10 6
* The power consumption of
ACO6800+ISD, ACO6800+DSD, ACO6800+ASID, and
ACO6800+IDSD, listed as <12 W, is measured at around 11.5 W.
† The power consumption of ACO6800+ISCST, listed as <13 W, is measured at around 12.5 W.
