Harris ACO6800+ISD - ACO6800+ASID Parameters

72 ACO6800+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 7: ACO6800+ASID Parameters, LEDs, and Alarms
ACO6800+ASID Parameters
Table 7-1. ACO6800+ASID Parameters
Group Parameter Name Function Options
General
Serial Number [RO] Displays the serial number of the module <string>
Factory Recall Sets your module back to factory default
settings
•On
• Off
Soft Reboot Activates a soft reboot of the module
•On
• Off
ACO Service Switch Settings
Output Source [RO] Displays the current output source
• Input 1
• Input 2
Switch High Priority Sets the high priority for switching
• GPI Input
•Manual
•Alarms
Switch Medium Priority Sets the medium priority for switching
• GPI Input
• Manual
•Alarms
Switch Low Priority Sets the low priority for switching
• GPI Input
•Manual
• Alarms
Alarm Switch Level Sets the level for alarm auto switch 1 to 10 (6)
Manual Switch Sets what the output source will be when a
channel is switched manually
• Disable
• Switch to A1
• Switch to A2
Alarm Switch Mode Sets the module for Automatic, non-resetting
mode. Automatic returns to primary input after
alarm clears and non-resetting must be switched
back to the primary input manually
• Automatic
• Non-resetting
Relay Bypass Activates the relay bypass
•On
• Off
Relay Status [RO] Displays whether or not the relay is active
•On
•Off
ACO Service GPIO Status
GPI In Trigger Level Sets the level at which an alarm is triggered for
the GPI Input
• Active Low
• Active High
GPI Out Trigger Level Sets the level at which an alarm is triggered for
the GPI Output
•Active Low
• Active High
GPI Input_1 [RO] Displays whether or not GPI Input_1 has been
switched to 1
•N/A
• Switch to 1
