Harris ACO6800+ISD - Propagation Delay; Power Consumption

ACO6800+ Installation and Operation Manual 109
Copyright © 2009, Harris Corporation
Chapter 9: Specifications
Propagation Delay
Power Consumption
Table 9-7. ACO6800+DSD and ACO6800+IDSD Propagation Delay
Specifications
Standard Propagation Delay
525/625 3.3 µsec
1080i/59.94
1080p/29.97
1080p/23.98
720p/59.94
1080i/50
1080p/25
1080p/24
720p/50
1080i/60
1080p/30
720p/60
1.0 µsec
Table 9-8. ACO6800+ISCST Propagation Delay Specifications
Frame Rate Standard Propagation Delay
59.94 Hz 525 1 frame
1080i 1 frame
720p 1 frame
50 Hz 625 1 frame
1080i 1 frame
720p 1 frame
23.98 Hz 1080p 1 frame
25 Hz 1080p 1 frame
Table 9-9. ACO6800+ASID Propagation Delay Specifications
Standard Propagation Delay
ASI < 30 µsec typical
Table 9-10. Power Consumption Specifications
Module Power Consumption
ACO6800+
ISD <12 W
ACO6800+DSD <12 W
