38 ACO6800+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 4: ACO6800+ISD Parameters, LEDs, and Alarms
OutA EDH Control 1, 5 Inserts or clears the EDH when the
input online is SD-SDI
Note This parameter is not available
in ASI mode, and is grayed out when
the selected input is HD.
• Insert
• Clear
ACO Group A > Out B Settings
OutB Source 4, 6 Select output source for Out B
• Follow Out A
• Input A1
• Input A2
OutB EDH Control 4, 7 Inserts or clears the EDH when the
input online is SD-SDI
Note This parameter is not available
in ASI mode, and is grayed out when
the selected input is HD.
• Insert
• Clear
Table 4-1. ACO6800+ISD Parameters (Continued)
Group Parameter Name
Bank, Switch
Function Options
