ACO6800+ Installation and Operation Manual 45
Copyright © 2009, Harris Corporation
Chapter 4: ACO6800+ISD Parameters, LEDs, and Alarms
SDI CC
EIA/CEA-608-B
Missing (525 only)
Reports that the standard definition CC data on line
21 field 1 is not detected
1 240.0 2.0
SDI CC
EIA/CEA-708-B
Missing
Reports that the high definition CC data on line 21
(284) is not detected
1 240.0 2.0
SDI WSS Missing
(625 only)
Reports that the presence of Wide Screen Signaling
for Wide Screen Format is not detected
1 240.0 2.0
SDI Luma Peak Reports that the HD or SD luma component has
exceeded the threshold defined by the Luma Peak
Threshold parameter
1 240.0 2.0
SDI Luma Low Reports that the HD or SD luma component
remains below the threshold defined by the Luma
Low Threshold parameter
1 240.0 2.0
SDI Chroma Peak Reports that the HD or SD chroma component has
exceeded the threshold defined by Chroma Peak
Threshold parameter
1 240.0 2.0
SDI Chroma Low Reports that the HD or SD chroma component
remains below the threshold defined by the Chroma
Low Threshold parameter
1 30.0 2.0
SDI Video Black Reports that the HD or SD video level does not
exceed the level defined by the Video Black
Threshold parameter
6 240.0 2.0
SDI CC/XDS Data
Missing (525 only)
Reports that the standard definition CC/Extended
Data Services on line 21 field 2 is not detected
1 240.0 2.0
SDI VChip Data Missing Reports that VChip data is not present on Line 21
Field 2
1 240.0 2.0
SDI Video Frozen Reports that the HD or SD content in the video
frame is not changing
130.02.0
SDI AFD Missing Reports that AFD is not present 1 30.0 2
SDI Embedded
Ch(01–16) Peak
Detects that the peak audio level meets or exceeds
the limit set in the Peak Audio Threshold parameter
130.02.0
SDI Embedded
Ch(01–16) Loss of
Sound
Detects that the audio amplitude has fallen below
the limit set in the Loss of Sound Threshold
parameter
130.02.0
SDI Embedded
Ch(01–16) Vbit Set
Detects a set V-Bit in the embedded audio source 1 1.0 2.0
Table 4-7. ACO6800+ISD Subdevice Alarms (Continued)
Alarm Name Alarm Description
Alarm Option Default
Settings
Alarm
priority
Trigger
(s)
Clear
(s)
