Chapter 5: ACO6800+DSD Parameters, LEDs, and Alarms
Group A Switch Low
Priority
1, C Sets the low priority for switching
• GPI Input
•Manual
• Alarms
Group A Alarm Switch
Level
1, D Sets the level for alarm auto switch 1 to 10 (6)
Group A Manual Switch 1, E Sets what the output source will be when
a channel is switched manually
• Disable
• Switch to A1
• Switch to A2
Group A Relay Bypass 1, 1 Activates the relay bypass
•On
• Off
Group A Relay Status
[RO]
Displays whether or not the relay is
active
•On
•Off
ACO Group A > General Purpose Interface
Group A GPI In Trigger
Level
1, 2 Sets the level at which an alarm is
triggered for the Group A GPI Input
• Active Low
• Active High
Group A GPI Out
Trigger Level
1, 3 Sets the level at which an alarm is
triggered for the Group A GPI Output
• Active Low
• Active High
Group A GPI Input_1
[RO]
Displays whether or not GPI Input_1 has
been switched to A1
•N/A
• Switch to A1
Group A GPI Input_2
[RO]
Displays whether or not GPI Input_2 has
been switched to A2
•N/A
• Switch to A2
Group A GPI Input_3
[RO]
Displays whether or not GPI Input_3 has
been switched to Relay Bypass
•N/A
• Relay Bypass
Group A GPI Output_1
[RO]
Displays whether or not A1 is selected as
current output source
•N/A
• Input A1 online
Group A GPI Output_2
[RO]
Displays whether or not A2 is selected as
current output source
•N/A
• Input A2 online
Group A GPI Output_3
[RO]
Displays whether or not the relay bypass
has been activated
•N/A
• Signal Bypass
ACO Group A > MISC Settings
OutA OSD Enable 1, 4 Enables the on-screen display
Note This parameter is not available in
ASI mode.
• Off
•On
OutA EDH Control 1, 5 Inserts or clears the EDH when the input
online is SD-SDI
Note This parameter is not available in
ASI mode, and is grayed out when the
selected input is HD.
• Insert
• Clear
Table 5-1. ACO6800+DSD Parameters (Continued)
Group Parameter Name
Bank,
Switch
Function Options
