Chapter 7: ACO6800+ASID Parameters, LEDs, and Alarms
Parameters > PSI > PAT
PAT Program Number
(1-16) [RO]
Displays the received program PAT Program
number in Decimal
Program number is
displayed
PMT PID (1-16) [RO] Displays the received program associated PMT
PID as Hex and [Decimal]
•N > A
• 0X#### [XXX]
Parameters > PSI > PMT
PMT Program Number
(1-16) [RO]
Displays the received program PAT Program
number in Decimal
Program number is
displayed
PMT Program PCR PID
(1-16) [RO]
Displays the received program associated PMT
program PCR PID as Hex and [Decimal]
•N > A
• 0X#### [XXX]
PMT Program Video PID
(1-16) [RO]
Displays the received program associated PMT
program Video PID as Hex and [Decimal]
•N > A
• 0X#### [XXX]
PMT Program Audio PID
(1-16) [RO]
Displays the received program associated PMT
program Audio (Main) PID as Hex and
[Decimal]
•N > A
• 0X#### [XXX]
PMT Program Audio PID
(1s-16s) [RO]
Displays the received program associated PMT
program Audio (Secondary) PID as Hex and
[Decimal]
•N > A
• 0X#### [XXX]
Parameters > Parameter Settings > ETR-290 > Priority 1 Alarms
PAT Repetition Allows selection of the PAT repetition rate for
alarm detection
0.1 to 5 seconds
PMT Repetition Allows selection of the discontinuity threshold
for alarm detection
0.1 to 5 seconds
PID Repetition Allows selection of the PID repetition threshold
for alarm detection
0 to 60 seconds
Parameters > Parameter Settings > ETR-290 > Priority 2 Alarms
PCR Repetition Allows selection of the PCR repetition rate for
alarm detection
Note A Program Clock Reference (PCR) is used
to re-generate the local 27 MHz system clock. If the
PCR does not have sufficient regularity, the clock
can jitter or drift and the receiver > decoder can
become unlocked. When irregularities occur
outside the PCR Error ranges, the PCR Error alarm
activates. In Digital Video Broadcasting (DVB), a
repetition period of not more than 40 ms is
recommended.
10 to 1000 ms
PCR Discontinuity Allows selection of the PCR discontinuity for
alarm detection
10 to 1000 ms
PCR Accuracy Threshold Allows selection of the PCR accuracy threshold
for alarm detection
100 -2000 ns
PTS Repetition Allows selection of the PTS repetition rate for
alarm detection
100 -2000 ms
Group Parameter Name Function Options
