Harris Corporation Constellation™
Installation and Commissioning 4-3
INSTALLATION AND
COMMISSIONING
Ensure that the test equipment has
• the current calibration
• the proper connector(s)
so that you will get a correct reading from the test
equipment.
Table 4-2: Recommended test equipment
Test
Equipment
Specification Model Function
Digital
multimeter
3-1/2 digits
Accuracy: 0.3% to ± 60
VDC, 2% from 10
mVAC
Fluke Model 77 or
equivalent
To test the
battery voltage.
To align the
antenna.
Frequency
counter
Universal frequency
counter with 10-digit
accuracy and 2160-
MHz ability
Agilent 53131A
or equivalent
To adj u s t the
frequency of the
Transmitter and
Receiver.
Power meter 100 kHz to 26.5 GHz
±1% accuracy
Agilent E4418B
or equivalent
RF transmitter
power output
Power sensor
−25 dBm to +33 dBm
(medium and high
power heads)
Agilent 8485A
(-30 to +20
dBm) Agilent
8481H
(-10 to +35
dBm) Agilent
8485D
(-20 to -70 dBm)
or equivalent
