Harris Corporation Constellation™
Configuring the Constellation Radio 6-5
CONFIGURING THE
CONSTELLATION
RADIO
ATPC, M12 PROTECTION, SVC, FAN, PATH
ALARMS MENU, AND CONFIG ALARM
Table 6-4: ATPC, M12 PROTECTION, SVC, FAN, PATH ALARMS
MENU, AND CONFIG ALARM
SYSTEM
Submenu
Selection Explanation
TX ATPC DISABLE HIGH Disable ATPC; set Tx at High power.
DISABLE LOW Disable ATPC; set Tx at Low power.
ENABLE Enable ATPC.
M12 PROTECTION NON REV Nonrevertive.
When this option is selected, an automatic
switching from the standby M12 Unit to
the working unit does not occur whenever
a failed unit is replaced by a working one.
REVERTIVE When this option is selected, an automatic
switching from the standby M12 Unit to
the working unit occurs whenever a failed
unit is replaced by a working one.
SVC OPTION INSTALL Choose this command to put the Service
Channel into service.
UNINSTALL Choose this command to put the Service
Channel out of service.
FAN OPTION INSTALL Choose this command for new installation
of the radio.
UNINSTAL Choose this command to put the Fan out
of service.
PATH A, B
ALARMS MENU
SHOW Displays the A and B alarms menu
HIDE If you choose HIDE, the RSL LOW and
SIGNAL DEGRADED alarms will not be
displayed.
CONFIG ALARM CLR/SET This item does not display for new
installation.
This alarm displays only if there is a
configuration alarm.
