Constellation™ 2002 June 20
4-6
Summary of the Installation Procedures
Table 4-4 is a summary of the installation procedures.
Turning on the Radio
Table 4-4: Installation procedures
Step Procedure For Details,
Go To
1
Ensure that the power breaker is off or that the fuse is
removed.
2
Install the Constellation Radio rack as specified in the
Sales Order Specific Information (Engineering Work
Order).
3
Ground the radio rack. page 4-9
4
Open and remove the Constellation doors. page 4-9
5
Connect the interconnection cables to the
Constellation backplane.
page 4-12
6
Connect the Constellation radio to other equipment. Appendix A
7
Connect the customer-configured alarm wires. page 4-32
8
Connect the Constellation to the antenna or to a
dummy load.
page 4-18
9
Test the office battery voltage. page 4-20
10
Connect the battery power wires to the Constellation. page 4-20
Table 4-5: Turn-on procedures
Step Procedure For Details,
Go To
1
Ensure that the correct fuses are installed in the Fuse
Panel.
page 4-22
