Harris Constellation - Figure 4-2: Door Latch; Figure 4-3: Door Straps

Constellation™ 2002 June 20
4-10
Figure 4-2: Door latch
b. The doors swing open 90 degrees.
c. For radios with straps (Figure 4-3) installed inside the door:
Pull the straps (on the left and right sides) to unfasten them.
Figure 4-3: Door straps
d. Lift up the doors to remove them from the card cage.
Left strap
Right strap
