Constellation™ 2002 June 20
4-30
The power at the top of the rack (TOR) = the power
meter reading + the coupling loss shown on the monitor
port label.
d. If the Power Meter reading does not equal the value calculated from
step c, use the Keypad to adjust the RF power out. Refer to the next
section for a detailed procedure.
e. If power adjustment is required, go to step f.
If power adjustment is not required, go to step p.
Keypad Procedure for Adjusting the RF Power Out.
Table 4-15: Power at antenna flange, MHSB configuration
TX Frequency
(GHz)
8T 16T 28T/DS3 OC3/3xDS3
Power (dBm)
6 29.1 28.1 28.6 28.6
7/8 27.1 26.1 26.6 27.1
10/11 25.6 24.1 24.6 24.6
