Harris Corporation Constellation™
Installation and Commissioning 4-7
INSTALLATION AND
COMMISSIONING
Do not continue until the radio has warmed up
(about 1 hour).
Summary of the Terminal Test
Table 4-6 is a summary of the terminal test procedures.
2
Turn on the power. page 4-23
3
Turn on the Power Supply switch. page 4-23
4
Ensure that the antenna port is terminated into a
dummy load or the antenna system before turning on
the TX switch.
5
Turn on the TX switch on the Transmitter Assembly. page 4-23
Table 4-5: Turn-on procedures
Step Procedure For Details,
Go To
Table 4-6: Terminal test procedures
Step Procedure For Details,
Go To
1
At the Transmitter Assembly, measure the reference
frequency.
page 4-23
2
Measure the reference frequency at the Receiver
Assembly.
page 4-25
3
Use a Power Meter and the Keypad to verify the RF
transmitter power output at the transmit monitor
port.
page 4-27
4
Perform loopback tests (through the Keypad). page 5-1
5
Perform BER tests from the Keypad page 4-32
