If you selected a T2 ADM for one of the channels, you must configure each of
the M12 Units listed below.
• M12-1 T2 ADD/DRP
• M12-2 T2 ADD/DRP
• M12-3 T2 ADD/DRP
• M12-4 T2 ADD/DRP
TRIBUTARIES from the CONFIGURATION
Submenu
Table 6-6: ADM for high capacity radios
ADM
Submenu
Selection Explanation
M12-1 T2
ADD/DRP
None
T2-1 ... 7
Do not drop any T2 signals into these M12 Units
T2 to drop into M12.
Table 6-7: TRIBUTARIES Submenu
TRIBUTARIES
Submenu
Selection Explanation
ENABLE DS-1, 2, 3
TRIBUTARY A1 TO 28
TRIBUTARY B1 TO 16
WAYSIDE
Choose ENABLE or DISABLE for
each tributary.
This command only masks the
alarm of the disabled tributary.
CODE TRIBUTARY A1 TO 28 CODE
TRIBUTARY B1 TO 16 CODE
Select the appropriate line code
for each tributary used.
AMI or B8ZS, HDB3
WAYSIDE CODE
WAYSIDE CODE
AMI or B8ZS
AMI or B8ZS, HDB3
EQUALIZER This item is compensation for
cable length between customer’s
equipment and the radio
equipment. It is applicable to DS
signals.
