Constellation™ 2002 June 20

6-8

DS3 EQUALIZER For a DS3 signal.

DS3-1, 2, 3 EQUALIZER For 3xDS3 signals: for each T3

tributary, select the range in

feet.

TRIB EQUALIZER Select the appropriate range in

feet for each tributary.

For an E1 signal: select E1 for

each tributary. Range in feet is

not available for E1.

WAYSIDE EQUALIZER

For a DS1 signal, select the

appropriate range in feet.

For an E1 signal, select E1

UNBALANCED or E1 BALANCED.

Table 6-7: TRIBUTARIES Submenu

TRIBUTARIES

Submenu

Selection Explanation
