Constellation™ 2002 June 20
4-8
Summary of the Hop Test
Network Element Address
Obtain a network element address from the network manager.
Verify the configurations listed in Table 4-8
(through the Keypad).
Table 4-7: Aligning the antenna procedure
Step Procedure For Details,
Go To
1
Ensure that the antenna is terminated into the
antenna system (and not to a dummy load).
Align the antenna at the Receiver Assembly.
page 4-32
Table 4-8: Hop test procedures
Step Procedure For Details,
Go To
1
The system configuration through the Keypad. page 6-1
2
If applicable, the add-drop for a repeater system. page 6-6
3
Configure the network management (through the
Keypad).
page 8-1
4
The tributaries. page 6-7
5
The relay outputs. page 6-9
6
The Service Channel. page 6-10
7
The protection system. page 6-3
page 6-5
8
Inform the network manager that the Constellation is
ready to be put into service.
