d. Connect a frequency counter to the REF MON port on the Receiver
Assembly (Figure 4-16).
e. To adjust the frequency, use the Keypad hidden-menu command
CONFIGURATION >
F1 + F3 or Ctrl B
> RX 100MHZ TUNE
f. Adjust the frequency to
100.000,000 MHz
±
(see table)
Year of Operation Tolerance
Initial adjustment ± 100 Hz
After one year of operation ± 200 Hz
Thereafter ± 300 Hz
