INTRODUCTION
CONTENTS
500C,500C/M
501C,501CM
503CX,503CXi,503CW,503CWD
FLASH SYNC
INPUT CABLE
ALWAYS
REQUIRED
907X
CFV II 50C CABLE FREE
OPERATION
555ELD
500EL/EL/M
500ELX/553ELX,555ELD
SWC/M
903SWC
905SWC
Modied202FA,203FE,205TCC,205FCC
WithFtypelensesandCF/CFi/CFElensesat
F-modesetting
503CW/503CWD
503CXi
+WinderCW
500EL,500EL/M
500ELX,553ELX
555ELD
PHOCUS
REMOTE CONTROL
2000FC,2000FC/M
2000FCW,2003FCW
201 F,
Unmodied203FE,205TCC,205FCC
ForfullaccesstoXCDLenses.
H,V,XPanandmostotherlenses
viaoptionaladapters.
Described in detail in a separate
userguide.
Any view camera
withHasselbladV
System adapter
1)
FlexBody
ArcBody
1)
1)
 Shiftsettingsarenotrecommendedoncameras
withwideanglelensesandashortlenstoimage
planedistance.E.g.theArcBody.
WithCtypelensesonly
(C-modesetting)
1.10 CONNECTIVITY CHART – MECHANICAL SHUTTERS
Exposure cable 503 CW
is required for Phocus
remote control of 503CW
+ Winder CW.
Exposure Cable EL is
required for Phocus
remote control of EL/ELM
and ELX use.
