REMOTE CONTROL OF A EL-TYPE CAMERA
Note!ForanELDcamera,noextracableisneeded.
ConnecttheexposurecableEL(A) between the CFV and
thesocketatthebottomrightoftheWinderELcamera.The
2.5mmconnectorshallbeconnectedfromtheELXsocketon
the CFV (B).
WhenthecameraisconnectedviaUSBtoacomputerrunning
Phocus,youcanreleasethecamerafromthecomputer.See
separatePhocususerguideformoredetails.
A
C
B
