4.1 PARTS, COMPONENTS, BUTTONS AND CONTROLS
AllpartsandfunctionmentionedinthisChapter,aredescribedinfurtherdetailinotherspecicsections.
1 Menu button
Thisbuttonopensthemainmenu.Ifthemainmenuis
alreadyactive,thecontrolscreenisshown.
2 Cross button
Functiondependsonscreeninformation.Thebutton
actsasdeleteimagebuttoninbrowsemode.Thebutton
movestheselectorupinmenus.Incontrolscreenitused
forparameterselection.
3 Star button
TheStarbuttonwillzoomoutto9-viewinbrowsemode.
Inliveviewthestarbuttonwillzoomintoforprecise
focusing.Itisalsousedasaselectbuttonwhencontrolling
camerasettingsusingbuttons.
4 Display button
Functiondependsonscreeninformation.Thebutton
changestheoverlayinliveviewmode.Inmenus,itmoves
theselectordown.Whenthecontrolscreenisactive,itis
usedforparameterselection.
5 On/Off and browse button
Along-press(pressandholdforonesecond)willturn
OnorOffthecameradependingonthepreviousstate.
Ashort-pressactivatesthedisplayandshowsthelast
capturedimage.
6 Status LED
Green color:indicatesthatthecameraisreadytomakea
capture.
Yellow colour:Thecameraisbusyandnotreadytomake
a capture.
Red color:Errorstate
Blinking:Theimageiswrittentothecardorhostcomput-
er.
7 Touch display
Multi-touchdisplaywithfulltouchsupporttocontrol
allsettingsofthecameraaswellaspanning,pinchand
spreadzoomforimagereview.Thedisplaycanbetilted
upto90degreesupwards.
Note!
YoucanforcetheCFVintostandbymodetosavepowerby
pressingandholdingtheMenubuttonandmakingashort-
pressontheOn/Offbutton.
