Hasselblad CFV II 50C - Page 27

1
2
3
4
5
1 Sensor
Pleasemakesuretoreadthecleaninginstructionsinthe
Appendixonpage110.
2 Contact for 200 Series cameras
Electricalcontactusedwithmodied200Seriescameras.
3 Release bar sensor
Usedtosynchronizeexposurewiththe500,ELandSWC
type cameras.
4 907X Contact
Contactusedwiththe907Xcamerabody.
5 555 ELD Contact
Contactusedwiththe555ELDcamera.
CFV II 50C USER GUIDE www.hasselblad.com
27
PARTS&CONTROLS
